Характеристики

• Устройства управления: Тёплым полом

• 5 - 30 °C, 50/60 Hz
• Rated voltage 250 V~
• Switching current 10 A
• Inductive load at cos phi 0,6 max. 4 A
• Switching temperature difference approx. 0,5 °C
• Night lowering approx. 4 °C

Neutral conductor necessary!

If the pre-set temperature is reached the contact opens.

• with imprint
• setting knob with temperature range limitation
• with on/off switch and indicator LED for "on"
• with thermal return
• with separate connection for night lowering
• e.g. for valve drives closed in de-energized state
• without spreader claws
• with plug-in terminals
